This Series has Been Discontinued
We Recommend the EUP-240SxxxSV Series as a Replacement
- High Level Input Surge Protection:
- 6kV DM, 10kV CM
- More Compact Design
- Suitable for Independent Use
- 5 Year Warranty
Life Time
118,000 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
7.40 x 3.47 x 1.50
Millimeters (L x W x H)
188 x 88 x 38
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 700 mA | 176 ~ 305 Vac | 179 – 357 Vdc | 250 W | EBC-255S105SV-0007 |
| 860 mA | 160 – 290 Vdc | EBC-255S105SV-0004 | ||
| 1050 mA | 160 – 238 Vdc | EBC-255S105SV-0000 |
File Name |
|---|
LED Driver Installation Instructions (Updated March 2015) |
LED Driver Installation Guidelines (Updated September 2018) |
