- Constant-Voltage Output
- Input Surge Protection:
- 4kV DM, 6kV CM
- SELV Output
- Suitable for Independent Use
- 5 Year Warranty
Life Time
96,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.50 x 2.66 x 1.56
Millimeters (L x W x H)
165 x 67.5 x 39.7
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 12 V | 176 ~ 305 Vac | 0 ~ 18.4 A | 220 W | EBV-250S012SV |
| 24 V | 0 ~ 10.5 A | 250 W | EBV-250S024SV | |
| 36 V | 0 ~ 7.0 A | EBV-250S036SV | ||
| 48 V | 0 ~ 5.3 A | EBV-250S048SV |
File Name |
|---|
LED Driver Installation Instructions (March 2015) |
LED Driver Installation Guideline (Updated September 2018) |
