- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 Certified (Part 251, 252, 253)
- 3-Timer-Modes Dimmable
- Dim-to-Off with Standby Power ≤ 0.5W
- Integrated Power Monitoring with High Accuracy up to ±1%
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous
- (Classified) Location
- Suitable for Luminaires with Protection Class I
- 5 Year Warranty
Life Time
104,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
7.40 × 2.52 × 1.44
Millimeters (L x W x H)
188 × 64 × 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 530 – 700 mA | 530 mA | 90 ~ 305 Vac 127 – 300 Vdc | 142 – 378 Vdc | 200 W | EUM-200S070ET |
| 700 – 1050 mA | 700 mA | 95 – 286 Vdc | EUM-200S105ET | ||
| 1050 – 1500 mA | 1050 mA | 67 – 190 Vdc | EUM-200S150ET | ||
| 1800 – 2800 mA | 2100 mA | 36 – 111 Vdc | EUM-200S280ET | ||
| 3500 – 5600 mA | 4200 mA | 18 – 57 Vdc | EUM-200S560ET |
